L6246 Automatic Horizontal Turning 1500mm Manual Metal Lathe Machine

Liên hệ nhà cung cấp Chat now

Những điểm chính về sản phẩm

Thuộc tính cụ thể của ngành

Các thuộc tính khác

Khu vực

Thương hiệu

Mã sản phẩm

Tên sản phẩm

L6246 Automatic Horizontal Turning 1500mm Manual Metal Lathe Machine

Nhà cung cấp

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

Thông tin nha cung cấp của bạn

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

2 yrs

Vị trí tại VN

Thời gian đáp ứng

≤2h

Tỷ lệ giao hàng đúng hẹn

95%

Sản phẩm Cửa hàng

Mô tả sản phẩm

Recommend Products

Products Description

Brief Introduction

Hardend and precision ground bedway,one piece complete stand

Euro-standard electrical control board available on request

Character

The surface fo the bed ways is supersonic frequency hardened and precision ground with a long service life.

The design of the main drive is optimized and the gears in the headstock are precision ground the noise of the machine is low and it`s sound is pleasing to hear.

Standard accessories	Optional Accessories
3-jaw chuck(160mm)	work light
M.T.6/4sleeve	quick change tool post
M.T.7/5sleeve	drill chuck with arbor
M.T.#5 dead center	4-jaw chuck(320mm)
tool box with tools	face plate
steady rest	leadscrew guard
follow rest	live center
change gears set	index turning tools
coolant system
splash guard

Specification

Max swing over bed	460mm
Max swing over slide	274mm
Max swing over gap	690mm
Center distance	1000mm(40”)/1500(60”)
Spindle hole	58mm
Spindle taper	M.T.NO.6
Range of spindle speeds	25-2000rpm
range of Longitudinal feeds	0.03-1.7mm/rev
range of Cross feeds	0.014-0.784mm/rev
range of metric threads	0.1-14mm
range of inch threads	2-112TPI
diametrical pitches range	4-112D.P.
module pitches range	0.1-7M.P.
taper of tailstock bore	M.T.#4
power of motor	4kw/5.5kw
packing size	2250/2800x1120x1730
Net/gross weight	1720/2045kg 2020/2385kg
